ATX Motherboard

Name: ATX Motherboard
Brand: IMPULSE TECHNOLOGY
Price: 20000.0 INR
Availability: InStock

Price 20000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Number

ATX Motherboard Specification

Equipment Type
ATX Motherboard

Application
Desktop PC Systems

Service Period
5 Years average usage

Usage
Personal Computer, Gaming, Office

Process
High-Precision Automated Assembly

Tolerance
0.5mm

Product Type
Desktop Motherboard

CPU Support
Intel LGA 1151 / AMD AM4 Socket

Design
ATX Form Factor

RAM
Supports DDR4 up to 64GB

Thickness
1.6mm

Color
Black/Blue

Technique
Multi-layer PCB

Supply Voltage
12V DC

Input Voltage
110V/220V AC via PSU

Material
PCB, Copper Circuitry

Output Voltage
5V / 3.3V / 12V (to components)

Brand Name
Generic

Processing
SMT and DIP soldering

Size
Standard ATX (12 x 9.6 inch)

Frequency
100 MHz Base Clock

Finish
Matte Solder Mask

Mounting Type
Screw Mount

Dimension (L*W*H)
305mm x 244mm x 38mm

Part
Motherboard

Standard
ATX 2.2

Humidity
10% ~ 85% (non-condensing)

Temperature
0C to 50C

IP Rating
IP20

Weight
1.2 kg

Surface Treatment
Lead-free HASL

Installation Guideline
Refer to manual, anti-static handling recommended

Model No
ATX-001

BIOS
UEFI AMI BIOS with Plug and Play

Audio
7.1 Channel HD Audio

Form Factor
ATX

Rear I/O Ports
VGA, HDMI, USB, LAN, Audio Jacks

Chipset
Intel H310 Express

USB Ports
6 x USB 3.0, 8 x USB 2.0

Storage Interface
4 x SATA III 6Gb/s ports

Integrated Graphics Support
Supports Intel HD Graphics (depending on CPU)

Power Connector
24-pin ATX main power, 8-pin CPU power

Expansion Slots
1 x PCIe x16, 2 x PCIe x1

LAN
Integrated Gigabit Ethernet

ATX Motherboard Trade Information

Minimum Order Quantity
1 Number

Delivery Time
8 Week

About ATX Motherboard

Key Features

Standard ATX form factor (305mm 244mm)
Support for Intel Core desktop processors up to 14th Gen
DDR4 / DDR5 memory support up to 192GB
Multiple display outputs including HDMI, DP, VGA, DVI, LVDS/eDP
Triple and quad display capability
Multiple PCIe and PCI slots for GPU, AI, frame grabber, and industrial expansion cards
High-speed networking with dual and triple 2.5GbE LAN support
RAID storage support with SATA and NVMe expansion
M.2 slots for NVMe SSD, WiFi, and 4G/5G modules
Rich industrial I/O including USB, COM, GPIO, Audio, and SIM support
TPM security support for industrial-grade protection
Wide operating temperature support for harsh environments
Designed for stable 24/7 industrial operation

Common Applications

Industrial Automation
AI Edge Computing
Machine Vision Systems
Industrial Servers
Smart Factory Solutions
Medical Imaging Equipment
Transportation Systems
Digital Signage
Industrial Networking
Data Processing Systems
Surveillance and Security Platforms

Popular Models

MA20-Q6700 High-performance ATX motherboard supporting Intel 12th/13th/14th Gen processors, DDR5 memory up to 192GB, triple 2.5GbE LAN, RAID support, and PCIe Gen4 expansion.
MA20-R6800 Industrial ATX board with Intel R680E chipset, advanced PCIe expansion, RAID storage, and industrial networking capabilities.
LA34-B7600 Intel B760 industrial motherboard with DDR5 support, multiple display outputs, and rich industrial I/O connectivity.
JLA20-10S Q470E-based industrial ATX motherboard designed for industrial control and automation systems with extensive PCIe expansion support.
