NUC industrial Cpu

Name: NUC industrial Cpu
Brand: IMPULSE TECHNOLOGY
Price: 20000.0 INR
Availability: InStock

Price 20000.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

NUC industrial Cpu Specification

Color
Industrial Black

Usage
Factory Automation, Machine Vision, Industrial Control

CPU Support
Intel Celeron / Core i3/i5/i7 (8th/10th Gen optional)

Service Period
Long-Term Operation 24/7

Supply Voltage
DC 12V/19V

Equipment Type
Embedded Computer

Material
Aluminum Alloy + Metal Case

Output Voltage
Standard DC Out (Available for Extensions)

Processing
CNC Chassis for Durability

IP Rating
IP40

Application
Automation, Embedded Systems, Data Acquisition

Technique
Precision Machined

RAM
Up to 32GB DDR4

Part
Industrial Embedded PC

Standard
CE/FCC

Product Type
Mini Industrial PC

Installation Guideline
Wall Mount/VESA mount supported

Weight
1.5kg

Brand Name
NUC

Temperature
-20C to 60C

Finish
Powder Coated

Thickness
3mm Chassis

Input Voltage
DC 12/19V

Surface Treatment
Anodized

Process
Fanless/Passive Cooling

Size
Compact Form Factor

Frequency
50Hz/60Hz

Tolerance
High Thermal Tolerance

Mounting Type
Wall/VESA Mount

Dimension (L*W*H)
150 x 125 x 55 mm

Humidity
10% - 90% (Non-condensing)

Design
Compact & Fanless

Model No
NUC Industrial CPU

LAN Ports
2 x Gigabit Ethernet

Audio
Line Out, Mic In

Graphics
Integrated Intel HD Graphics

USB Ports
4 x USB 3.0, 2 x USB 2.0

Power Consumption
Max 45W

Shock Resistance
IEC60068-2-27/29 Compliant

Storage
Dual M.2 Slots, 1x 2.5" SATA HDD/SSD

Serial Ports
2 x RS232/RS485

Expansion Slots
1x Mini-PCIe

Cooling System
Fanless, Passive Cooling

Vibration Resistance
IEC60068-2-64 Compliant

Operating System Support
Windows 10, Linux compatible

NUC industrial Cpu Trade Information

Minimum Order Quantity
1 Number

Delivery Time
8 Week

About NUC industrial Cpu

Key Features

Standard ATX form factor (305mm 244mm)
Support for Intel Core desktop processors up to 14th Gen
DDR4 / DDR5 memory support up to 192GB
Multiple display outputs including HDMI, DP, VGA, DVI, LVDS/eDP
Triple and quad display capability
Multiple PCIe and PCI slots for GPU, AI, frame grabber, and industrial expansion cards
High-speed networking with dual and triple 2.5GbE LAN support
RAID storage support with SATA and NVMe expansion
M.2 slots for NVMe SSD, WiFi, and 4G/5G modules
Rich industrial I/O including USB, COM, GPIO, Audio, and SIM support
TPM security support for industrial-grade protection
Wide operating temperature support for harsh environments
Designed for stable 24/7 industrial operation

Common Applications

Industrial Automation
AI Edge Computing
Machine Vision Systems
Industrial Servers
Smart Factory Solutions
Medical Imaging Equipment
Transportation Systems
Digital Signage
Industrial Networking
Data Processing Systems
Surveillance and Security Platforms

Popular Models

MA20-Q6700 High-performance ATX motherboard supporting Intel 12th/13th/14th Gen processors, DDR5 memory up to 192GB, triple 2.5GbE LAN, RAID support, and PCIe Gen4 expansion.
MA20-R6800 Industrial ATX board with Intel R680E chipset, advanced PCIe expansion, RAID storage, and industrial networking capabilities.
LA34-B7600 Intel B760 industrial motherboard with DDR5 support, multiple display outputs, and rich industrial I/O connectivity.
JLA20-10S Q470E-based industrial ATX motherboard designed for industrial control and automation systems with extensive PCIe expansion support.
